Rumor: 2016 Shelby GT350R Destroys Z/28′s Lap Time at the Nurburgring

The rumor mill has been working overtime with the most recent claim that the new 2016 Shelby GT350R lapped the Nurburgring in 7 minutes and 32.19 seconds! Going around the ring at that speed would mean the new GT350R faster than the Chevrolet Camaro Z/28 and the Porsche 997 GT3 RS.

There has been an abundance of spy video of the Shelby GT350 and 350R testing on the Nurburgring, but there was never any reported lap times. The story of the GT350′s blistering fast lap originally broke from Horsepower Kings and has since made its rounds around the internet.

While there is no (known) video of this lap time to substantiate the claim, it is entirely possible and probable that the new S550 Shelby Mustang lapped the ring in this time, if not a little quicker. The GT350/GT350R is direct competition for the Z/28 Camaro and was created with the Camaro in mind. While the new GT350 was being developed, it was being held up to and pitted against competitors like the Camaro Z/28 as well as the Porsche GT3 and BMW M4. The GT350R’s time of 7:32.19 is 5 seconds faster than the Z/28′s 7:37.40 lap time at the Nurburgring.

Both the GT350 and the track ready GT350R benefit from the new Voodoo engine, which is the most powerful NA production V8 to come from Ford, but the GT350R benefits from a long list of parts to help it conquer the track. Removing the AC unit, exhaust resonators, stereo, rear seats, trunk floorboard and carpet, backup camera, tire sealer and inflator saved a ton of weight, which becomes even more pronounced when you factor in added carbon fiber pieces including carbon fiber wheels.

It is only a matter of time until Ford releases official numbers, including lap times and videos. Be sure to check back for updated details and numbers.

What are your thoughts on the GT350R’s lap time? Is it one for the record books or does it not quite make the cut? Comment below!



Here’s what it’s like to drive the very first Ford Mustang cop car

Filed under: , , , , , , ,

Cop cars are cool. Ford Mustang cop cars are even cooler. That's why Road and Track scribe Zach Bowman sought out the very first Mustang SSP for a must-read feature.

Continue reading Here's what it's like to drive the very first Ford Mustang cop car

Here's what it's like to drive the very first Ford Mustang cop car originally appeared on Autoblog on Thu, 29 Jan 2015 13:20:00 EST. Please see our terms for use of feeds.

Permalink | Email this | Comments

What you missed on 1.26.15

Filed under: , , , , , , , ,

We drive the Jeep Renegade Trailhawk and capture its off-road credentials on video, find out that the Ford Shelby GT350R Mustang is very quick and that the next Ford Raptor will be very powerful. All that and more, just a single click away!

Continue reading What you missed on 1.26.15

What you missed on 1.26.15 originally appeared on Autoblog on Mon, 26 Jan 2015 19:30:00 EST. Please see our terms for use of feeds.

Permalink | Email this | Comments

How does a Mustang’s Overdrive Work?

Going back 25 years, overdrive was a highlighted feature on the Mustang. Starting in 1984, all Mustangs were finally equipped with an overdrive gear. Prior to that, select transmissions had it, but were only available if you wrote a larger check. It was a big deal to have overdrive back then, as it wasn’t an industry standard (it was something to separate a vehicle from the competition), but more importantly, it greatly increased fuel efficiency. Nowadays, you probably will not see ‘overdrive’ talked about (or advertised) to the extent it was back then. Why? Today, Ford has standardized this feature across their fleet, and due to this, overdrive is rarely ever highlighted as part of the vehicle’s feature list (it will still be in the brochure, but no longer a key feature like it was in the 80’s). However, this does not mean having an overdrive has lost its importance in the Mustang world! Like it did back then, overdrive gears give our beloved Pony cars some fuel efficiency. How exactly does it work? Let’s delve into it below, starting by explaining the concept of overdrive, and then continuing with the functionality of it between manual and automatic transmissions.

What is Overdrive?

As mentioned, overdrive is a feature of all modern transmissions that when used, decreases fuel consumption. The faster an engine spins the more fuel it will require. The faster a vehicle is moving, the faster the engine has to spin to propel it, right? Well, what if there is a way to decrease the engine RPM’s, but maintain overall vehicle speed? This would clearly lead to better gas mileage, and is exactly how an overdrive gear works. Essentially, an overdrive gear is a special gear that when engaged, rotates the output shaft of the transmission at a higher rate than the engine.  For example, a driveshaft that is rotating at 2000 RPM whereas the engine is rotating at 1500 RPM is being overdriven by 33%, or a ratio of 0.67. All Mustangs produced with an overdrive transmission have had an overdrive ratio ranging between 0.625 and 0.725. Again, this means the engine is rotating at 62.%-72.5% (the specific ratio depends on the year and transmission in question, as overdrive ratios are non-variable) the speed of the output or driveshaft. So, say the ratio is 0.625 for this particular case, for every turn the driveshaft makes, the engine has only rotated 0.625 times. Conversely, for every rotation of the engine, the driveshaft is spinning ~1.38 times. By using overdrive, we have successfully lowered the engine RPM’s, thereby saving gas, but have maintained cruising speed.

Overdrive in a Manual Transmission

The way overdrive works in a manual transmission is actually very simple, it is just another gear installed inside the transmission, on the cluster, that when selected, has a gear ratio of less than one. To reiterate, the gear ratio is the ratio between input revolutions and output revolutions, measured relative to input. Thus, when reading a gear ratio of 2.95:1, it is to be interpreted as the engine spins 2.95 times for every 1 revolution of the transmission gear. Input speed is 2.95 revolutions, output speed is 1 revolution. When talking about overdrive gears, they will have a ratio of less than one (meaning output is faster than input).

The highest gear available on your manual transmission will be the overdrive gear (either 5th gear or 6th gear). To engage overdrive, all you need to do is shift into the highest gear.

Overdrive in an Automatic Transmission

Unfortunately, the way an automatic transmission uses overdrive is not quite as simply as a manual transmission, simply based on the fact that automatic transmissions are more complicated pieces themselves! An automatic transmission uses a torque converter to transmit power via the engine and transmission, whereas a manual transmission Mustang uses a direct clutch. Without diving too deep into the workings of a torque converter, a basic overview is probably needed.

A torque converter is used to transmit power from the engine to the transmission, as mentioned above. However, the fashion it does so is completely different than a typical clutch setup. Torque converters rely on fluid couplings between two halves to transmit power. The impeller half is connected to the engine, whereas the turbine half is connected to the turbine shaft (which connects to the transmission). As the engine revs up, the impeller side spins (remember, impeller side is directly connected to engine), pushing transmission fluid (a special oil) over to the turbine side. Due to some very cool physics and engineering (which we will not discuss here), the turbine side rotates, which rotates the turbine shaft and subsequently turns the transmission.

With that said, the good news is, it gets simpler from here. The important parts are: 1) impeller is connected to engine, and spins at same speed; 2) impeller pushes fluid to turbine side, which rotates turbine at a different speed. Wait a minute, this looks like the classic formula… input is greater than output, therefore the converter is slipping. When overdrive engages in an automatic transmission, it rectifies this converter slip by locking the converter (i.e: converter turns at engine speed) and then engages special planetary overdrive gears within the transmission.

Having written all that, I suppose that overdrive within an automatic transmission does not work very differently than a manual transmission. The concept is the same – use a special gear that when driven, has greater revolutions than is applied. The complicating factor for automatic transmissions is the torque converter (the ‘middleman’).

When should you use Overdrive?

As often as you can! The more you can use overdrive, the more gas you can save. Automatic Mustangs will robotically manage this for you. When the conditions are right (vehicle speed and load), it will automatically engage. In fact, overdrive is enabled by default on automatic cars. There is a button to manually override it (usually near the shifter, or on the shift handle itself), but unless you are towing (with a Mustang?) or are travelling through very steep terrain, there is no benefit to disabling it. In fact, it will hurt fuel economy.

The same applies to manual-shift cars. When cruising, use it as often as possible, when the circumstances dictate. Obviously, it will not be effective to cruise in overdrive at 30 MPH, but when approaching highway speeds, definitely shift into OD.

Ford Shelby GT350R sets 7:32.19 Nurburgring lap time

Filed under: , ,

Ford's track-tuned Shelby GT350R Mustang has reportedly trounced the Chevy Camaro Z/28's lap time to become the fastest muscle car on the Nurburgring.

Continue reading Ford Shelby GT350R sets 7:32.19 Nurburgring lap time

Ford Shelby GT350R sets 7:32.19 Nurburgring lap time originally appeared on Autoblog on Mon, 26 Jan 2015 11:00:00 EST. Please see our terms for use of feeds.

Permalink | Email this | Comments
